SUNFLX SEI-8K-SP - Cable and Circuit Breaker Requirements

13
4.2、Cable & circuit breaker requirement
•
PV INPUT
Model
Cable Diameter
Max. PV Input Current
Circuit Breaker Spec
SEI-8K-SP
5mm²/ 10 AWG
22A
2P-25A
SEI-10K-SP
5mm²/ 10 AWG
22A
2P-25A
SEI-12K-SP
5mm²/ 10 AWG
22A
2P-25A
• AC INPUT
•
Generator
• BATTERY
• AC OUTPUT
Model
Cable diameter
Max input current
Circuit Breaker Spec
SEI-8K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
SEI-10K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
SEI-12K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
Model
Cable diameter
Max input current
Circuit Breaker Spec
SEI-8K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
SEI-10K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
SEI-12K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
Model
Cable diameter
Max input current
Circuit Breaker Spec
SEI-8K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
SEI-10K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
SEI-12K-SP
13mm
2
/6AWG(L/N)
63A
2P-63A
Model
Output model
Cable diameter
Circuit Breaker Spec
SEI-8K-SP
Signal phase
13mm
2
/6AWG(L/N)
2P-63A
SEI-10K-SP
Signal phase
13mm
2
/6AWG (L/N)
2P-63A
SEI-12K-SP
Signal phase
13mm
2
/6AWG (L/N)
2P-63A
