SUNFLX SEI-8K-SP - WIFI Port for Remote Monitoring

41
RJ45
Definition
Pin 1
5V
Pin 2
GND
Pin 3
/
Pin 4
/
Pin 5
/
Pin 6
/
Pin7
RS485-A
Pin 8
RS485-B
6.3、WIFI port
The RS485-1 port is used to connect to the Wi-Fi/GPRS data acquisition module, which allows the user
to view the operating status and parameters of the inverter via the mobile phone APP.
