Sungrow SG2K5-S User Manual

5 Electrical Connection User Manual
40
1
2
≤
45
mm
12
-
16
mm
12mm-16mm 16mm-21mm10mm-12mmD
D
Seal
3. Fully insert the conductors into the corresponding cable holes and close
the clamp.
1
2
L
N
PE
Observe the terminal layout on the block. Do not connect the phase
wires to "PE" terminal or PE wire to "N" terminal. Otherwise,
unrecoverable damage to the inverter may follow.
4. Assemble the terminal block to the housing and mate them together until
a “Click” is heard or felt. Tighten the cable gland with a torque of 6.5 Nm.
