Sungrow SG50CX Quick Guide

TD_20210219_SG30-50-110CX Commissioning Guide_V1.1 Page 14 of 21
© SUNGROW AUSTRALIA GROUP PTY LTD All rights reserved.
As we continuously improving our products, changes to this document may occur without notice.
3.4 Add Energy Meter
The energy meter needs to be manually added which is same as any other 3
rd
party
equipment.
To add the energy meter, click ‘Add device’ and select a device type in the pop-up
window and fill in the required information (Add device for DTSD1352/DTSU666
energy meter and device address: 254).
If it is a DTSU666 meter and not show up in the list, you may need to update the
Logger1000/EyeM4 first. Refer to the Part 5 in this document.
Logger1000
EyeM4
If the meter connected with A2 and B2
on the Logger1000, the port number on
the portal is COM2.
If the meter connected with A3 and B3
on the Logger1000, the port number on
the portal is COM3.
Ensure the port is COM1

Sungrow SG50CX Specifications

General

Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of MPPTs	4
Rated AC Output Power	50 kW
Max. AC Output Current	76 A
Frequency	50 Hz / 60 Hz
Efficiency	98.6%
Start Voltage	200 V
Number of DC Inputs per MPPT	2
Max. AC Apparent Power	55 kVA
AC Voltage Range	310 V - 480 V
Power Factor at Rated Power	1
Adjustable Power Factor Range	0.8 leading - 0.8 lagging
THDi	< 3%
DC Switch	Yes
AC Surge Protection	Type II
DC Surge Protection	Type II
Protection Class	I
Cooling Method	Smart forced air cooling
Protection Degree	IP66
Protection Level	IP66
Operating Temperature Range	-25°C to +60°C
Humidity	0-100%
AC Output Voltage	3 / N / PE, 220 V / 380 V, 230 V / 400 V
