3. To improve the safety of the system, set the “Import Power Limit” for the inverter immedi-
ately after completing the wiring. The formula used to calculate the import power limit should
be: Set value of Import Power Limit (kW) ≤ 3*230*0.8*rated current of the house's main
switch. For instructions on parameter setting, see "8.10.16 Import Power Limit".
6.4 External Protective Grounding Connection
Electric shock!
• Make sure that the grounding cable is connected reliably. Otherwise, it may
cause electric shock.
• Since the inverter is not equipped with a transformer, neither the negative elec-
trode nor the positive electrode of the PV string can be grounded. Otherwise,
the inverter will not operate normally.
• Connect the grounding terminal to the external protective grounding point be-
fore AC cable connection, PV string connection, and communication cable
connection.
• The external protective grounding point provides a reliable ground connection.
Do not use an improper grounding conductor for grounding, Otherwise, it may
cause product damage or personal injury.
• Depending on Local Rules, please also ground the PV panel subconstruction to
the same common grounding point (PE Bar) in addition to local lightning pro-
tection rules.
The external protective grounding terminal must meet at least one of the following
requirements.
• The cross-sectional area of the grounding cable is not less than 10 mm
2
for cop-
per wire or 16 mm
2
for aluminum wire. It is recommended that both the external
protective grounding terminal and the AC side grounding terminal be reliably
grounded.
• If the cross-sectional area of the grounding cable is less than 10 mm
2
for copper
wire or 16 mm
2
for aluminum wire, ensure that both the external protective
grounding terminal and the AC side grounding terminal are reliably grounded.
The grounding connection can be made by other means if they are in accordance
with the local standards and regulations, and SUNGROW shall not be held liable
for the possible consequences.
