Sungrow SH10T User Manual

89
Parameter
Explanation
Default
Range
DE AU
QU_Q3
Value of Q/Sn at P3 on the Q
(U) mode curve
0 -60% ~ 60%
QU_V4
Grid voltage limit at P4 on the
Q(U) mode curve
107%
AU: 115.2%
NZ: 110.8%
100% ~
120%
QU_Q4
Value of Q/Sn at P4 on the Q
(U) mode curve
60% 30% 0 ~ 60%
QU_
EnterPower
Active power for Q(U) function
activation
80% 20% ~ 100%
QU_ExitPower
Active power for Q(U) function
deactivation
10% 1% ~ 20%
QU_
EnableMode
Unconditional activation/deacti-
vation of Q(U) function
Yes
Yes / No /
Yes, Limited
by PF
* Curve C is reserved and consistent with Curve A currently.
figure 8-4 Q(U) Curve
There is no need to set initialization parameters of the EV charger because it can
operate automatically after being identified by iSolarCloud App.
8.6 Function Overview
The App provides parameter viewing and setting functions, as shown in the following figure.
User Manual 8 iSolarCloud App
