64
When wiring, make sure the arrow on the CT points in the direction from Grid to
Load.
Steps for connecting the Smart Energy Meter to the inverter with a communication
cable
1. Unscrew the swivel nut from the connector and take out the terminal block.
6 Electrical Connection User Manual
