User Manual 10 Appendix I: LCD Operation
75
10.2 LCD Menu Structure
Run Info ON / OFF Settings Time Country Fault Record
Restart
ON
OFF
Bat Usage Time
Reactive Power
Zero-export
Battery Type
Load Control
Comm. Param
DRM Switch
Prot. Param
Earth Fault
Main Menu
Power curve
Daily energy
Total energy
Battery info
Grid info
PV info
System info
DRM info
Inverter info
Password: 111
Off-grid Setting
Forced Charge
Active Power
Existing Sys
(1)
(3)
(4)
* Refer to 12.3 Active Power Response.
* Refer to 12.2 Reactive Power Regulation.
* Refer to 12.1 Demand Response Modes
(2)
Password: 111
PT1000 Switch
Factory Reset
* To enable/disable the DRM function
* To enable/disable the temperature sampling
Fig. 10-1 LCD Menu Tree
(1) The power value indicated represents the average value during the time interval. The
energy yields displayed are indicative only. For the actual yields, please refer to
the electric energy meter.
(2) The value of battery SOH will be displayed as “--” for Pylon US2000A and GCL
battery that do not have this parameter.
(3)
The “ON” option will be disabled when the DRM state is DRM0.
(4) The “Restart” option will appear only if an unrecoverable fault occurs.
The demand response mode (DRM), reactive power settings about Qt,
Q(p), Q(u), and power derating settings are valid only for Australia.
To Next Page
