Installation - Assembly Procedures
26525-01A
Attaching Legs to Bench
Lay the bench upside down on the floor.
Locate the two stand legs and attach to the
bench as shown below.
2. Turn bench right side up on floor.
Place so that the power cord connec-
tor is facing toward the wall outlet.
1. Using six 5/16” x 1” bolts and six
larger 5/16” washers (pre-installed,
remove from bottom of sunbed),
attach the stand legs with the skirt
mounting holes toward the back of
the bench as shown. Install center
bolt first. You may have to gently
push sides of legs in to align holes.
Tighten with the Allen wrench.
(ELECTRICAL CONNECTOR INDICATES
BACK OF BENCH)
SKIRT MOUNTING HOLES
