󱈞 How to use the imbedded handy controller
[Note]
When modifying the sequence by using the handy controller, the change in the sequence number is not displayed, so more care
should be exercised in conducting the modification.
※ Use and buttons when changing the value of sequence.
※ Use and buttons to move to the next sequence.
SequenceB-55Group B
Program Start
+
⇨⇨⇨
80[ms]Lapsed Time: Unit-1[ms]
T/T Sol. “ON”
Sequence Start
⇨⇨⇨⇨
W/P Sol. “ON”
66[ms]Lapsed Time: Unit-1[ms]
T/T Sol. “OFF”
⇨⇨⇨⇨
0 [ms]Sequence End
W/P Sol. “OFF”
Lapsed Time: Unit-1[ms]
⇨⇨⇨⇨
Sequence Save Group B
⇨⇨
