7-58
② FRAME ORIGIN
This moves the frame back to the start position. Start position of the frame must be set so the frame can move
back to the previous position in case of a power failure.
③ FRAME LIMIT SET
As there is no physical frame limit switch, you have to set the limit in the software. Input two points on the frame
to set the limit (see picture below.)
It produces an error message when the embroidery material goes over the frame limit set. To have the error
message function, select “DATA SET-UP”→“ EMB FUNCTION”→“ 15] FRAME LIMIT”and set “YES.”
This function is not available on SWF/
□
-W1201 and SWF/
□
-1204.
(P1X, P1Y)
(P2X, P2Y)
Ex) Setting P1X=100, P1Y=500, P2X=1500, P2Y=－500
Move the cursor to “3.FRAME
LIMIT”and press
FRAME LIMIT SET
PRESS SET KEY
P1X : 100, P1Y : 300
Press to end the
process.
CUTTING NEEDLE SET
1 => USE, 0 => NO
NO. 1 5 9
[100001000000]
To Next Page
