SunStar SWF/C-UK1502 User Manual

PARTS OF THE MACHINE
CHAPTER 3
3-1
[Fig.3-1]
Machine Body
Table
Upper thread stand
Main shaft drive motor
Rotary hook base
Trimming cam box
Arm
Color Change
Upper thread holder
Head
Thread tension
adjustment board
Sub-controller
X-axis driving system
Y-axis driving system
Emergency stop
S/B button
Tubular frame
Border frame
Controller box
Operation box
Encoder
Main power switch
Leveling base
Sub support
Thread detector
Emergency power
switch
3-1) SWF/C-U SERIES

SunStar SWF/C-UK1502 Specifications

General

Brand	SunStar
Model	SWF/C-UK1502
Category	Sewing Machine
Language	English
