5-8
5-5) NEEDLE STOP CLUTCH
As illustrated in [Fig.5-9], the needle bar will not move when you pull the jump clutch lever. Push the level to the
opposite direction of the operator to do move needle bar up and down.
Jump manual clutch lever
[Fig.5-9]
CAUTION
The trimmer and the take-up lever continue to move even when the needle bar is
stopped by the clutch. Avoid any operations, i.e. threading the needle or changing
thread.
Long-time operation of the needle bar with the clutch may damage the bar controller.
