5-5
Clutch
[Fig.5-6]
5-4) NEEDLE STOP CLUTCH
The needle bar moves when the red signal on the clutch is facing the operator ([Fig.5-6]). Turn the clutch 90°in the
direction of the arrow to stop the needle bar.
CAUTION
The trimmer and the take-up lever continue to move even when the needle bar is
stopped by the clutch. Avoid any operations, i.e. threading the needle or changing
thread.
Long-time operation of the needle bar with the clutch may damage the bar controller.
