SUNSTONE Orion mPulse - Page 21

Questions? Call or Text +1-801-658-0015 • 17
e Micro Welder Experts
2.0mm Thick Ring
Metal Tip Shape Energy Notes
14k Gold Sharp 30 ws
Butt weld with 90º
electrode angle
Butt Weld
24k Gold Sharp 30 ws
Silver Blunt 30 ws
Platinum Sharp 30 ws
Stainless Steel Sharp 30 ws
Palladium Sharp 30 ws
Titanium Sharp 30 ws
Brass Sharp 30 ws
Add Material (30 AWG Laser Wire)
Metal Tip Shape Energy Notes
14k Gold Sharp 12 ws
T-Joint weld with
45º electrode angle
T-Joint Weld
24k Gold Sharp 12 ws
Silver Sharp 15 ws
Platinum Sharp 15 ws
Stainless Steel Sharp 10 ws
Palladium Sharp 10 ws
Titanium Sharp 15 ws
Brass Sharp 12 ws
2.0mm Thick Ring
Metal Tip Shape Energy Notes
14k Gold Sharp 17 ws
Wire at 45º angle;
Electrode touching
work piece next
to wire
Add Metal
Weld
24k Gold Sharp 15 ws
Silver Sharp 20 ws
Platinum Sharp 20 ws
Stainless Steel Sharp 15 ws
Palladium Sharp 15 ws
Titanium Sharp 20 ws
Brass Sharp 17 ws
Retip Prong (26 AWG Wire)
Metal Tip Shape Energy Notes
14k Gold Sharp 10 ws
Wire at 45º angle;
Electrode touching
work piece next
to wire
Add Metal
Weld
24k Gold Sharp 7 ws
Silver Sharp 10 ws
Platinum Sharp 10 ws
Stainless Steel Sharp 7 ws
Palladium Sharp 7 ws
Titanium Sharp 10 ws
Brass Sharp 10 ws
Orion mPulse Welder Specications
Weld Technology Type Pulse Arc
Weld Modes 1
Pre-Programmed Metal Settings 0
Customizable Save Setting 0
Languages Not Applicable
Display 4.4” Touchscreen
Energy 3-30 Ws
Weld Spot Diameter 1.0-1.25mm
Footprint 5.5”x5.25”x3.625”/13.79x13.34x9.21cm
Weight 2 lbs. 6 oz./1.07kg
Pulse Frequency 0..5 Hrz
Microscope Magnication 5X (>IR 16/>UV 16)
Darkening Shutter Visibility: Shade 3 to Shade 12
