● Definition : Active Output1.
Field Definitions Unit Remark
CMD_ID “Enable1” Enable Output1
<example>
[command] ST4345CMD;850000;02;Enable1
[response] ST4345CMD;Res;850000;010;Enable1
[response] ST4345CMD;Res;850000;010;Enable1NoUse (in case that IN type is set to ‘No Use’).
<notes>
** Output1 line goes to active status.
** If OUT1 set with immobilizer, output1 line goes to active status gradually with pulse in driving mode.
** If OUT1 set with pulse type, output1 line generates pulse and returns inactive state after pulsing out
automatically.
4-11-6. Disable1
● Definition : Inactive Output1.
Field Definitions Unit Remark
CMD_ID “Disable1” Disable Output1
<example>
[command] ST4345CMD;850000;02;Disable1
[response] ST4345CMD;Res;850000;010;Disable1
[response] ST4345CMD;Res;850000;010;Disable1NoUse (in case that IN type is set to ‘No Use’).
<notes>
** Output1 line goes to inactive status.
4-11-9. Request IMSI
● Definition : Request the unique SIM ID.
Field Definitions Unit Remark
CMD_ID “ReqIMSI” Request IMSI (unique SIM ID)
If received, device sends IMSI of using SIM.
<example>
[command] ST4345CMD;850000;02;ReqIMSI
