ST4345 User Manual
9
OUT1_TYPE ‘0’ ~ ‘5’ 0 = GPIO
1 = immobilizer
2 = Immobilizer & Auto active
Auto active means immobilizer is activated
automatically
when the vehicle starts parking.
3 = Pulse
4 = LED Out for indicating call status. Refer 7-2-3.
5 = Buzzer
OUT1_ACTIVE ‘0’ or ‘1’ 0 = Open when out1 is active
1 = GND when out1 is active
PULSE1_NO String Pulse number when out1 type set to pulse.
Range : 0 ~ 9999
If pulse no is 9999, pulsing runs permanently.
PULSE1_ON String 100ms Active time of pulse1
Range : 0 ~ 9999
It should be set with even number.
PULSE1_OFF String 100ms Inactive time of pulse1
Range : 0 ~ 9999
It should be set with even number.
BAUD ‘0’ ~ ‘4’ It’s available when extra events support RS232.
Baud-rate
0 = No use
1 = 4800bps
2 = 9600bps
3 = 19200bps
4 = 38400bps
5 = 115200bps
If the device does not support RS232, it should be 0.
