16
Step 1: take the 1PC double-ended crimping φ8 OT
terminal wire number three, and lock the upper
terminal hole of the bottom product at one end.
The effect picture after locking
Step 2: Bend the cable and lock the other end
of the OT terminal in the underside hole of the
upper product.
Step 3: For example, step one locks another wire
in the upper terminal hole of the upper product.
Step 4: Cover the terminal protection cover as
shown.
After the protective cover is covered, the
renderings are locked, and the other cables are
locked in turn.
Connector installation instructions
The power cable connection is shown in the figure, press and hold the red unlock button, and there
is a clicking sound for the plug connection.
