Superior™ DRT2000 and DRC2000 Direct-Vent Gas Fireplaces
71
REPLACEMENT PARTS
Table 54: Installer Replacement Parts
Description
DRC2033 / DRT2033 DRC2035 / DRT2035 DRC2040 / DRT2040 DRC2045 / DRT2045
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
Catalog
Number
Qty
1 Touch-Up Paint 90L73 1 90L73 1 90L73 1 90L73 1
2 Blower Assembly 80L84 1 80L84 1 80L84 1 80L84 1
3 Volcanic Stone 80L42 1 80L42 1 80L42 1 80L42 1
4 Electronic Pilot Assembly, Natural Gas H7268 1 H7268 1 H7268 1 H7268 1
5 Electronic Pilot Assembly, Liquid Propane H7269 1 H7269 1 H7269 1 H7269 1
6 Electronic DFC Wire Harness Assembly H8601 1 H8601 1 H8601 1 H8601 1
7 Electronic DFC Ignition Board H7272 1 H7272 1 H7272 1 H7272 1
8 Electronic Power Transformer H8006 1 H8006 1 H8006 1 H8006 1
9 Electronic Battery Holder (for backup batteries) H8803 1 H8803 1 H8803 1 H8803 1
10 Electronic Ground Wire H7278 1 H7278 1 H7278 1 H7278 1
11 Electronic ON/OFF Switch 27K30 1 27K30 1 27K30 1 27K30 1
12 Electronic Control Module H7272 1 H7272 1 H7272 1 H7272 1
13 Millivolt Pilot Assembly, Natural Gas 69L17 1 69L17 1 69L17 1 69L17 1
14 Millivolt Pilot Assembly, Liquid Propane 69L18 1 69L18 1 69L18 1 69L18 1
15 Millivolt Piezo Igniter 10K86 1 10K86 1 10K86 1 10K86 1
16 Millivolt Piezo Igniter Wire 56L21 1 56L21 1 56L21 1 56L21 1
17 Millivolt Pilot Generator 60J79 1 60J79 1 60J79 1 60J79 1
18 Millivolt Thermocouple 74L57 1 74L57 1 74L57 1 74L57 1
19 Millivolt Pilot Tube 74L56 1 74L56 1 74L56 1 74L56 1
20 MIllivolt Electrode and Cable H6212 1 H6212 1 H6212 1 H6212 1
21 Orifice Holder H7257 1 H7257 1 H7257 1 H7257 1
22 Gas Flex Line Connector 93L32 1 93L32 1 93L32 1 93L32 1
23 Gas Valve, Electronic, Natural Gas F1831 1 F1831 1 F1831 1 F1831 1
24 Gas Valve, Electronic, Liquid Propane F1832 1 F1832 1 F1832 1 F1832 1
25 Gas Valve, Millivolt, Natural Gas F1833 1 F1833 1 F1833 1 F1833 1
26 Gas Valve, Millivolt, Liquid Propane F1834 1 F1834 1 F1834 1 F1834 1
27 Contemporary Burner Assembly F1843 1 F1843 1 F1843 1 F1904 1
28 Traditional Burner Assembly F1843 1 F1843 1 F1844 1 F1843 1
29 Vent Restrictor Base H8987 1 H8987 1 H8987 1 H8987 1
30 Vent Restrictor Wing H8988 1 H8988 1 H8988 1 H8988 1
31 Gas Train Assembly Gasket H1264 2 H1264 2 H1264 2 H1264 2
32 Door Latch Assembly H1264 2 H1264 2 H1264 2 H1264 2
33 Brass Orifice, Female—Natural Gas LB-69547 1 21L8201 1 99K7401 1 19L5201 1
34 Brass Orifice, Female—Liquid Propane 35M9101 1 100934-08 1 62L3701 1 60J8001 1
35 Assembly Harness, Control H8601 1 H8601 1 H8601 1 H8601 1
36 Glass Media, 5 lb bag—Reflective Black H8412 1 H8412 1 H8412 1 H8412 1
37 Logset F1883 1 F1829 1 F1830 1 F1884 1
