PARTS
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 39 of this manual. Catalog numbers
provided for clarity.
KEY
NO. PART NO. DESCRIPTION QTY.
1 122653-01 Door Assembly, 36" • • 1
122653-02 Door Assembly, 42" • • 1
2 122950-02 Bottom Door Assembly, 36" • • 1
122950-01 Bottom Door Assembly, 42" • • 1
3 121301-01 Face Assembly, 36" • • 1
121301-02 Face Assembly, 42" • • 1
4 122952-02 Screen Door Kit, 36" • • 1
122952-01 Screen Door Kit, 42" • • 1
5 ** Firebox Face • • • • 1
6 122842-03 Hearth Assembly, 36" NG • 1
122842-04 Hearth Assembly, 36" Propane/LP • 1
122842-01 Hearth Assembly, 42" NG • 1
122842-02 Hearth Assembly, 42" Propane/LP • 1
123781-01 Hearth Assembly, 36" NG, High Altitude 1
123781-02 Hearth Assembly, 42" NG, High Altitude 1
7 123210-01 Grate, 36" • • 1
123210-02 Grate, 42" • • 1
8 122652-01 Door Latch • • • • 2
9 ** Firebox Leg • • • • 4
10 ** Firebox Bottom • • • • 1
11 121431-01 Gasket, 36" • • 1
111913-02 Gasket, 42" • • 1
12 122919-01 Draft Diverter • • • • 1
13 ** Air Exchange • • • • 1
14 ** 5" Gasket • • • • 1
15 ** 5" Inner Connector • • • • 1
16 ** A/E Insulation • • • • 1
17 ** Firebox Surround • • • • 1
18 ** Firebox Top • • • • 1
19 ** Relief Assembly • • • • 2
20 ** Relief Bracket • • • • 4
21 ** Top Plenum • • 1
22 ** Rear Plenum • • 1
23 ** 5" Gasket • • • • 1
24 ** Connector, 8" x 3.25" • • • • 1
25 121295-01 36" Fireplace Surround • • 1
121302-01 42" Fireplace Surround • • 1
26 110037-01 Electrical Duct Assembly • • • • 1
27 117891-01 Fireplace Handle • • • • 4
28 120520-01 Refractory Retainer • • • • 3
29 20280 Top Spacer • • • • 4
30 ** Top Insulation • • • • 1
31 ** Fireplace Top • • 1
32 ** Hearth Side Spacer • • • • 2,3
33 ** Hearth Front Spacer • • 1
34 123182-01 Log #1 • • • • 1
35 123181-01 Log #2 • • 1
36 123211-01 Log #3 • • 1
37 125104-01 Draft Shield 36" • • 1
125104-02 Draft Shield 42" • • 1
38 109720-03 Spacer Clearance • • • • 3
**Not a eld replaceable part.
F1322/F1323
F1324/F1325
F1326/F1327
F1328/F1329
