SUPERMAX DUAL DRUM HEAD ASSEMBLY PARTS LIST
Ref.
Number
Description
Part Number
Qty./
Unit
SM25x2
Both
Models
SM37x2
1
DUST COVER
40-1525
40-3237
1
2
DUST COVER HANDLE
80-2841
1
3
#8x1/2" SELF TAPPING SCREW
10-3904
2
4
1/4"–20x1/2" ROUND HEAD MACH SCREW
10-3205
8
5
1/4" INTERNAL TOOTH LOCK WASHER
11-0504
8
6
DUST COVER MOUNT
40-0240
40-4243
1
7
HINGE
40-0225
2
8
1/4" SAE WASHER
11-0205
8
9
1/4"–20 HEX NUT
12-0001
8
10
3/8"–16 x1" HEX HEAD BOLTS
10-9205
8
11
5/16" WROUGHT WASHER
11-9103
8
12
3/8"–16 FLANGED LOCK NUT
12-0209
8
13
1/4"-28x1/4" SOCKET HEAD SET SCREW (BEARING)
10-8602
8
14
5/16"–18x1" CARRIAGE HEAD BOLT
10-1204
6
15
5/16"–18x1 1/4" HEX HEAD BOLT
10-9106
2
16
5/16" SAE WASHER
11-0206
10
17
5/16" I.D. SPACER
30-1305
2
18
DRUM BEARING
50-3067
4
19
OUTBOARD DRUM MOUNT BKT.
40-0519
1
20
5/16"–18 HEX NUT
12-0003
8
21
SECONDARY DRUM ADJ. KNOB
80-3135
2
22
5/16" I.D. SHAFT COLLAR WITH SET SCREW
20-1102
2
23
OUTBOARD SECONDARY DRUM ADJ. BKT.
40-0527
1
24
5/16" LOCK WASHER
11-0010
2
25
OUTBOARD SECONDARY DRUM INDICATOR
95-1659
1
26
BRASS SPACER
30-1303
2
27
3/8" SPRING WASHER
20-1165
2
28
EXTENSION SPRING
20-3210
2
29
1/4" x 1" KEY STOCK
20-0762
2
30
OUTBOARD INDICATOR NEEDLE
40-0531
1
31
OUTBOARD ABRASIVE FASTENER
21-1173
2
32
#6–32x3/8" FLAT HEAD PHILLIPS SCREW
10-3003
4
33
SANDING DRUM
30-1200
30-3100
2
34
INBOARD ABRASIVE TAKEUP FASTENER
21-1172
2
35
INBOARD INDICATOR NEEDLE
40-0530
1
36
INBOARD SECONDARY DRUM INDICATOR
95-1660
1
37
INBOARD SECONDARY DRUM ADJ. BKT.
40-0526
1
38
1/2"–13x2" HEX HEAD BOLT
10-0407
1
39
1/2" INTERNAL TOOTH LOCK WASHER
11-0508
1
40
INBOARD DRUM MOUNT BKT.
40-0520
1
41
5/16"–18 RETAINING NUT
20-1159
2
42
1/2" I.D. SPACER
30-1304
1
43
IDLER PULLEY
50-1258
1
44
1/2" SAE WASHER
11-0209
1
45
1/2" LOCK WASHER
11-0013
1
(Continued on page 44)
