SuperMax 25 - SUPERMAX CONVEYOR & MOTOR PARTS LIST (Contd.); Part Number Details

46 SUPERMAX OWNER’S MANUAL
SUPERMAX CONVEYOR & MOTOR PARTS LIST (Cont’d.)
Ref.
Number
Description
Part Number
Qty./
Unit
SM25
Both
Models
SM37
20
BOTTOM COVER
40-4116
1
21
#10–24 RETAINING NUT
20-1155
2
22
#10–24x3/8" SLOTTED HEX HEAD SCREW
10-3803
2
23
CONTROL BOX BASE BRACKET
40-4115
1
24
1/4"–20x1/2" ROUND HEAD MACH SCREW
10-3205
3
25
SWITCH BRACKET, SINGLE PHASE
40-5005
1
25
SWITCH BRACKET, THREE PHASE
40-0124
1
26
SWITCH BOX
72-5400-2
1
27
ON/OFF SWITCH (DRUM), SINGLE PHASE
72-5400-1
1
27
ON/OFF SWITCH (DRUM), THREE PHASE
72-1311
1
28
1/4"–20 HEX NUT
12-0001
3
29
LARGE STRAIN RELIEF
72-1404
5
30
CORD SET, SINGLE PHASE
72-5315
1
30
CORD SET, THREE PHASE
72-5305
1
31
#6-32x1–1/4" PHILLIPS PAN HEAD SCREW
10-3902
2
32
KNOB
72-1270-1
1
33
SMALL STRAIN RELIEF
72-6102
1
35
180-VOLT GEAR MOTOR
71-1171
1
37
5/16"–18x1/2" HEX HEAD BOLT
10-9101
4
38
CONTROL HOUSING
40-5013
1
39
INTELLISAND CONTROLLER, SINGLE PHASE
72-2280
1
39
INTELLISAND CONTROLLER, THREE PHASE
72-2270
1
40
#6-32 NUT
12-9001
2
41
#6 WASHER
11-0202
2
42
5/16"–18 RETAINING NUT
20-1159
4
43
1/4"–20x1/4" SOCKET HEAD SET SCREW
10-8802
2
44
COUPLING (CONVEYOR)
30-3102
1
45
5/16"–18x3/4" CARRIAGE BOLT
10-1203
4
46
5 H.P. TEFC ELECTRIC MOTOR, SINGLE PHASE
70-0507
1
46
5 H.P. TEFC ELECTRIC MOTOR, THREE PHASE
70-1503
1
47
3/8" WROUGHT WASHER
11-0104
2
48
5/16"–18 FLANGED LOCK NUT
12-0207
4
49
LOWER INNER BELT GUARD
40-1000
1
50
#10–24 RETAINING NUT
20-1157
2
51
4 1/2" DRIVE PULLEY
50-0450
1
52
1/4"x1" KEY STOCK
20-0762
1
53
5/16"–18x3/8" SOCKET HEAD SET SCREW
10-8903
1
54
CORD SECTION, SINGLE PHASE
72-5315
1
54
CORD SECTION, THREE PHASE
72-5305
1
55
RETAINING CLIP
72-6210
1
56
V-BELT– SINGLE DRUM, 25”
50-2021
1
– DUAL DRUM, 25”
50-2023
1
56
V-BELT– DUAL DRUM, 37”
50-2030
1
57
5/16" I.D. THIN WASHER
72-1270-3
1
58
5/16"–32 JAM NUT
72-1270-4
1
59
CONVEYOR BELT (NOT SHOWN)
60-0324
60-0337
1
