Supermicro AOC-UIBQ-m1 User Manual

v
Introduction
About this Manual
This manual is written for system integrators, PC technicians and knowledgeable PC
users who intend to integrate SuperMicro's AOC-UIBQ-m1/m2 add-on card add-on card
to their system.
Product Features
The AOC-UIBQ-m1/m2 add-on card offers the following features:
• Mellanox® ConnectX-2 QDR
• Single QSFP connector (AOC-UIBQ-m1) or dual QSFP connectors
(AOC-UIBQ-m2)
• 40Gb/s per port
• PCI-e x8 Gen.2, Low Profile, UIO form factor
• Virtual Protocol Interconnect (VPI)
• 1us MPI ping latency
• CPU off-load of transport operations
• End-to-end QoS and congestion control
• Hardware-based I/O virtualization
• TCP/UDP/IP stateless off-load
• Fibre Channel encapsulation (FCoIB or FCoE)
• External optical media adapter and active cable support
• Both standard and low profile brackets available
• Dimensions: 5.63” (14.29cm) x 2.5” (6.35cm) (length x width)
NOTE: The AOC-UIBQ-m1/m2 add-on card may require a riser card for
mounting in some systems.
NOTE: The AOC-UIBQ-m1/m2 add-on card is designed for UIO Supermicro
motherboards and server systems. Please go to www.supermicro.com for the
latest list of supported platforms.
