Page #14 background imageLoading...
Page #14 background image
14
H11DSi / H11DSi-NT User's Manual
Note: The table above is continued on the next page.
Motherboard Features
CPU
Dual EPYC 7001/7002* Series Processors, in Socket SP3. (*AMD EPYC 7002 series drop-in support requires board
revision 2.x)
Memory
2 TB of ECC DDR4 2666 MHz speed/ 4TB of ECC DDR4 3200 MHz* speed, RDIMM/LRDIMM/3DS/NVDIMM memory in
Sixteen (16) slots (*Board reversion 2.x required)
DIMM Size
Up to 128GB size at 1.2V
Chipset
System on Chip
Expansion Slots
2 x PCI-E 3.0 x16
3 x PCI-E 3.0 x8
2 x Internal NVMe Ports (PCI-E 3.0 x4)
M.2 Interface: 1 SATA/PCI-E 3.0 x2
M.2 Form Factor: 2280, 22110
M.2 Key: M-Key
Network
Dual RJ45 LAN Ports (H11DSi-NT: Intel X550-BT2 / (H11DSi: I350-BT2)
ATEN IPMI from ASPEED AST 2500 BMC for gigabit RJ45 port
Graphics
ASPEED AST2500 BMC chip with one (1) VGA port
I/O Devices
COM Port One (1) COM connector on rear I/O panel
SATA/NVMe Ports
Eight (8) SATA 3.0 ports (iPASS)
Two (2) SATA-DOM ports
Two (2) internal NVMe ports (H11DSi-NT only)
Peripheral Devices
Two (2) USB 3.0 “Type A” ports on the rear I/O panel (USB 4/5)
Two (2) USB 2.0 “Type A” ports on the rear I/O panel (USB 0/1)
One (1) USB 2.0 header for front control panel (USB 2/3)
Motherboard Features

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Supermicro H11DSi and is the answer not in the manual?

Supermicro H11DSi Specifications

General IconGeneral
ECCYes
Memory voltage1.2 V
Memory slots typeDIMM
Number of memory slots12
Supported memory typesDDR4-SDRAM
Maximum internal memory2000 GB
Supported memory clock speeds2666 MHz
Component forPC
Motherboard chipsetSystem on Chip
Motherboard form factorExtended ATX
Motherboard chipset familyAMD
PS/2 ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Number of SATA III connectors10
Number of DIMM slots16
Supported RDIMM module capacity8GB, 16GB, 32GB, 64GB
BIOS typeAMI
ACPI version5.1
BIOS memory size128 Mbit
On-board graphics card modelAspeed AST2500
Storage temperature (T-T)-40 - 70 °C
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)5 - 95 %
Operating relative humidity (H-H)8 - 90 %
Wi-FiNo
Ethernet interface typeGigabit Ethernet
PCI Express x8 (Gen 3.x) slots3
Processor socketSocket SP3
Supported storage drive interfacesSATA III
Weight and Dimensions IconWeight and Dimensions
Depth331 mm
Width305 mm
