Supermicro H11DSi User Manual

41
Chapter 2: Installation
Fan Headers
There are eight fan headers on the motherboard. These are 4-pin fan headers; pins 1-3
are backward compatible with traditional 3-pin fans. The onboard fan speeds are controlled
by Thermal Management (via Hardware Monitoring) in the BIOS. When using Thermal
Management setting, please use all 3-pin fans or all 4-pin fans.
Fan Header
Pin Denitions
Pin# Denition
1 Ground (Black)
2 +12V (Red)
3 Tachometer
4 PWM Control
Headers
Chassis Intrusion
A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable
from the chassis to the header to inform you when the chassis is opened.
Chassis Intrusion
Pin Denitions
Pins Denition
1 Ground
2 Intrusion Input
Disk-On-Module Power Connector
The Disk-On-Module (DOM) power connectors at JSD1 and JSD2 provide 5V power to a
solid-state DOM storage device connected to one of the SATA ports. See the table below for
pin denitions.
DOM Power
Pin Denitions
Pin# Denition
1 5V
2 Ground
3 Ground
SATA Ports
The H11DSi / H11DSi-NT has eight (8) available SATA 3.0 ports (CPU1-SATA0~3, CPU2-
SATA0~3) on two iPASS connectors that are supported by CPU1 and CPU2. These use an
iPASS breakout cable to support 4 ports per connector. There are also two (2) SATA ports
(P2-SATA0, P2-SATA1) that are supported by CPU2 and also provides integrated DOM (Disc
On Module) power.

Supermicro H11DSi Specifications

General

ECC	Yes
Memory voltage	1.2 V
Memory slots type	DIMM
Number of memory slots	12
Supported memory types	DDR4-SDRAM
Maximum internal memory	2000 GB
Supported memory clock speeds	2666 MHz
Component for	PC
Motherboard chipset	System on Chip
Motherboard form factor	Extended ATX
Motherboard chipset family	AMD
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Number of SATA III connectors	10
Number of DIMM slots	16
Supported RDIMM module capacity	8GB, 16GB, 32GB, 64GB
BIOS type	AMI
ACPI version	5.1
BIOS memory size	128 Mbit
On-board graphics card model	Aspeed AST2500
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Wi-Fi	No
Ethernet interface type	Gigabit Ethernet
PCI Express x8 (Gen 3.x) slots	3
Processor socket	Socket SP3
Supported storage drive interfaces	SATA III

Weight and Dimensions

Depth	331 mm
Width	305 mm
