H11SSL Motherboard Series User's Manual
Standby Power Header (JSTBY1)
The Standby Power header is located at JSTBY1 on the motherboard.
Standby Power
Pin Denition
Pins Denition
1 +5V Standby
2 Ground
3 Wake-up
IPMB System Management Bus Header (JIPMB1)
A System Management Bus header for IPMI 2.0 is located at JIPMB1. Connect the appropriate
cable here to use the IPMB I
2
C connection on your system.
IPMB Header
Pin Denitions
Pin# Denition
1 Data
2 Ground
3 Clock
4 No Connection
Main Power Supply Connector (JPWR2)
The primary power supply connector (JPWR2) is an ATX power connector that the power
supply plugs into directly.
ATX Power 24-pin Connector
Pin Denitions
Pin# Denition Pin # Denition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 Ground 3 Ground
16 PS_ON 4 +5V
17 Ground 5 Ground
18 Ground 6 +5V
19 Ground 7 Ground
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 Ground 12 +3.3V
