Chassis SC743 User's Manual
Front Features
The SC743 is a tower chassis. See the illustration below for the features included on the
front of the chassis.
Figure 1-2. Chassis Front View
Front Chassis Features
Item Feature Description
1 Control Panel Front control panel with LEDs and buttons (see preceding page)
2 Peripheral Drive Bays Three 5.25" bays for optional peripherals such as a DVD drive
3 Lock Front bezel lock
4 Drive Bays Eight 3.5" bays for hot-swap hard drives behind front bezel
5 Drive Indicators Eight pairs of LED status indicators for drives
3
1
2
2
4
2
5
