11
Chapter 1: Introduction
Rear Chassis Features
Item Feature Description
1 Power Supply Most models have P/S 2 power supplies
2 I/O Back Panel Rear I/O ports
3 Fans Two 8-cm exhaust fans
4 Expansion Slots Seven PCIe expansion card slots
Figure 1-3. Chassis Rear View
Rear Features
The illustration below shows the features included on the rear of the chassis.
1
4
3
2
