Chapter 1: Introduction
Chapter 1
Introduction
Supermicro's SC743 chassis series is optimized for the latest Intel Xeon processor and is also
compatible with previous generation Intel and AMD single/dual processor-based motherboards.
Utilizing redundant, high-efciency power supplies (95+%) and eight hot-swap 3.5" drive bays,
this chassis offers reliable performance with problem-free maintenance. Designed with 100%
cooling redundancy using a combination of high-performance fans, the chassis minimizes
the probability of system downtime or performance degradation from thermal-related issues.
With seven tool-less PCIe expansion slots, and 6-pin power connectors supporting up to
three high-end graphics cards, and it is quick to congure and easy to operate. Optionally,
this tower can be converted to mount in a standard rack.
1.1 Overview
This chapter provides a brief outline of the functions and features of the SC743 chassis.
Models are listed below.
SC743 Chassis Models
Model HDD I/O Slots Power Supply
CSE-743AC-1K26B-SQ 8x SAS3/SATA 7x FF 1200W
CSE-743TQ-903B-SQ 8x SAS3/SATA 7x FF 900W
CSE-743AC-668B 8x SAS3/SATA 7x FF 668W
1.2 Unpacking the System
Inspect the box in which the chassis was shipped, and note if it was damaged. If any
equipment appears damaged, le a damage claim with the carrier who delivered it.
