13
Chapter 1: Introduction
Connector Description
USB4 Front Accessible USB 3.0 Type A Port
VGA VGA Port
USB4 USB Type A Header
USB5/6, USB7/8 Front Panel USB 2.0 Headers
VGA Back Panel VGA Port
LED Description Color/State Status
LED1 Onboard Power LED Solid Green: Power On
System Power On
LEDM1 BMC Heartbeat LED
Blinking Green: BMC
Normal
UIDLED1 UID LED
Solid On: Overheat,
Blinking: PWR Fail or Fan Fail
