SuperServer E200-9A User's Manual
3.5 LED Indicators
LAN LEDs
Each Ethernet port on the I/O back panel has two LEDs. One LED indicates activity when

connection.
1GbE LAN LEDs
(Connection Speed Indicator)
LED Color Denition
Off
No connection
or 10 Mb/s
Green 100 Mb/s
Amber 1 Gb/s
IPMI-Dedicated LAN LEDs
A dedicated IPMI LAN is also included on the motherboard. The amber LED on the right
of the IPMI LAN port indicates activity, while the green LED (Link) on the left indicates the
speed of the connection.
IPMI LAN LEDs
Color Status Denition
Off Off No Connection
Green Link/Speed 100 Mb/s
LAN 1/LAN 2
IPMI LAN
(X8ST3-F)
Activity LED
Link LED
LAN 1/LAN 2
IPMI LAN
(X8ST3-F)
Activity LED
Link LED
Onboard Power LED
LED1 is an Onboard Power LED. When this LED is lit, it means power is present on the
motherboard. In suspend mode, this LED will blink on and off. Be sure to turn off the system
and unplug the power cord(s) before removing or installing components.
Onboard Power LED Indicator
LED Color Denition
Off
System Off (power cable not
connected)
Green System On
BMC Heartbeat LED
LEDM1 is the BMC heartbeat LED. When the LED is blinking green, BMC is functioning
normally.
