Chapter 3 Motherboard Connections
Power LED
The Power LED connection is located on pins 15 and 16 of JF1.
Power LED
Pin Denitions (JF1)
Pin# Denition
15 3.3V
16 Power LED
HDD LED/UID Switch
The HDD LED connection is located on pins 13 and 14 of JF1. Attach a cable here to indicate
the status of HDD-related activities, including SATA activities.
HDD LED
Pin Denitions (JF1)
Pin# Denition
13 3.3V Standby/UID Switch
14 HDD Active
