SuperServer E200-9A User's Manual
VGA Enable/Disable
Jumper JPG1 allows you to enable or disable the VGA port using the onboard graphics
controller. The default setting is Enabled.
VGA Enable/Disable
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
ME Manufacturing Mode Select



ME Manufacturing Mode
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 Manufacturing Mode
BIOS Recovery


BIOS Recovery
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 BIOS Recovery
Watch Dog
JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system
when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the
system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt
signal for the application that hangs. Watch Dog must also be enabled in BIOS. The default
setting is Reset.
Note: When Watch Dog is enabled, users must write their own application software to disable
it.
Watch Dog
Jumper Settings
Jumper Setting Denition
Pins 1-2 Reset (Default)
Pins 2-3 NMI
Open Disabled
