SuperServer E300-9D User's Manual
Quick Reference Table
Jumper Description Default Setting
JBT1 CMOS Clear Open: Normal, Closed: Clear CMOS
JI
2
C1, JI
2
C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled)
JNS1 OCuLink to 4x SATA or PCI-E x4 Selection Pins 2-3: (PCI-E x4)
JPG1 Onboard VGA Enable/Disable Pins 1-2 (Enabled)
JPME2 Manufacturing Mode Select Pins 1-2 (Normal)
JWD1 Watch Dog Timer Pins 1-2 (Reset)
LED Description Status
LED1 Power LED Solid Green: Power On
LED2 UID LED
LED3 Overheat (OH)/PWR Fail/Fan Fail LED
Solid Red: Overheat
Blinking Red: PWR Fail or Fan Fail
LEDBMC BMC Heartbeat Blinking Green: BMC Normal
Connector Description
BT1 Onboard Battery
FAN1 - FAN2, FANA CPU/System Fan Headers
IPMI_LAN Dedicated IPMI LAN Port
JD1 Speaker Header (Pins 1-4: Speaker)
JF1 Front Control Panel Header
JIPMB1 System Management Bus Header (for IPMI only)
JL1 Chassis Intrusion Header
JPI
2
C1 Power I
2
C System Management Bus (Power SMB) Header
JPH1 4-pin Power Connector for HDD use
JPV1 8-pin 12V DC Power Input (Required for both 12V only and 24-pin ATX power)
JSMB1 System Management Bus Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Connector
JUIDB1
LAN1 - LAN2 10 Gigabit (RJ45) LAN Ports
P1_NVME0 OCuLink Connector (to 4x SATA or PCI-E x4)
PJ1 Header for ATX Power Signal 5VSTBY/Power ON/Power GOOD/Ground
(CBL-PWEX-1063)
S-SATA0 - S-SATA3 SATA 3.0 Ports
S-SGPIO1 Serial General Purpose I/O Header
SLOT7 PCI-E 3.0 x8 Slot
USB0/1 USB 2.0 Header
USB2/3 Back Panel USB 3.0 Ports
VGA VGA Port
