SuperServer E300-9D User's Manual
System Features
Motherboard
X11SDV-4C-TLN2F
Chassis
Compact Embedded Mini ITX Box, SCE300
CPU
Intel Xeon D-2123IT (System on a Chip)
Memory
Four DDR4 DIMM sockets; supports up to 512GB DDR4 ECC RDIMM or up to 64GB DDR4 ECC/non-ECC
UDIMM; Memory Type 2666/2400/2133MHz; DIMM Sizes 64GB, 32GB, 16GB, 8GB, 4GB
Expansion Slots
Storage Drives
One OCuLink port (or one PCI-E x4 slot for NVMe HDDs)
One PCI-E 3.0 x8 slot
Power
One external 120 or 150 watt DC power adapter
Input/Output Ports
LAN: Two RJ45 10GBase-T ports
IPMI: One dedicated LAN port
USB: Two USB3.0 ports
Display: VGA
Serial ATA: Four SATA 3.0 ports
DOM: SuperDOM (Disk on Module) power connectors
TPM 2.0 header
Cooling
Three 4-cm PWM chassis fans, plus a passive CPU heatsink
Dimensions
W x H x D: 10" (254 mm) x 1.7" (43 mm) x 8.9" (226 mm)
1.2 System Features
The following table provides an overview of the main features of the E300-9D. Please refer
