SuperServer E300-9D User's Manual
3.2 Headers and Connectors
Fan Headers
The X11SDV-4C-TLN2F has three 4-pin fan headers (FAN1, FAN2, FANA). These headers are
backwards-compatible with the traditional 3-pin fans. However, fan speed control is available
for 4-pin fans only by Thermal Management via the IPMI 2.0 interface. Refer to the table

Fan Header
Pin Denitions
Pin# Denition
1 Ground (Black)
2 2.5A/+12V (Red)
3 Tachometer
4 PWM_Control
Speaker Header
On the JD1 header, pins 1-4 are for the external speaker.
Speaker Connector
Pin Denitions
Pin# Denition
1 P5V
2 NIC
3 NIC
4 R_SPKPIN
Chassis Intrusion
A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable
from the chassis to inform you of a chassis intrusion when the chassis is opened. Refer to

Chassis Intrusion
Pin Denitions
Pin# Denition
1 Intrusion Input
2 Ground
SATA Ports
Four SATA 3.0 connectors, supported by the Intel PCH chipset, are located on the
X11SDV-4C-TLN2F motherboard. These SATA ports support RAID 0, 1, 5, and 10.
