SuperServer E300-9D User's Manual
2.3 Motherboard Components
Processor
The E300-9D features an embedded Intel Xeon D-2123IT SoC processor.
Memory Support
The X11SDV-4C-TLN2F motherboard supports up to 512GB of DDR4 ECC RDIMM or up to
64GB of DDR4 ECC/non-ECC UDIMM; DDR4 2666/2400/2133MHz memory in four memory
slots. Populating these DIMM slots with memory modules of the same type and size will result
in interleaved memory, which will improve memory performance.
Note: Check the Supermicro website for recommended memory modules.
Memory Population Sequence
When installing memory modules, the DIMM slots should be populated in the following order:
DIMMA1, DIMMB1, DIMMD1, DIMME1.
Memory Population (Balanced)
DIMMA1 DIMMB1 DIMMD1 DIMME1
Total System
Memory
8GB 8GB
8GB 8GB 16GB
8GB 8GB 8GB 24GB
8GB 8GB 8GB 8GB 32GB
16GB 16GB 32GB
16GB 16GB 16GB 48GB
16GB 16GB 16GB 16GB 64GB
32GB 32GB 64GB
32GB 32GB 32GB 96GB
32GB 32GB 32GB 32GB 128GB
64GB 64GB 128GB
64GB 64GB 64GB 192GB
64GB 64GB 64GB 64GB 256GB
126GB 128GB 256GB
128GB 128GB 128GB 128GB 512GB
