Supermicro SuperServer E300-9D - Page 28

28
SuperServer E300-9D User's Manual
TPM/Port 80 Header
A Trusted Platform Module (TPM)/Port 80 header is located at JTPM1 to provide TPM support
and a Port 80 connection. Use this header to enhance system performance and data security.

Trusted Platform Module Header
Pin Denitions
Pin# Denition Pin# Denition
1 +3.3V 2 SPI_CS#
3 RESET# 4 SPI_MISO
5 SPI_CLK 6 GND
7 SPI_MOSI 8
9 +3.3V Stby 10 SPI_IRQ#
System Management Bus Header
A System Management Bus header for additional slave devices or sensors is located at

External I
2
C Header
Pin Denitions
Pin# Denition
1 Data
2 Ground
3 Clock
4 NC
