SuperServer E300-9D User's Manual
SMBus to PCI-E Slots

2
C1 and JI
2
C2 to enable PCI-E SMB (System Management Bus) support to
improve system management for the onboard PCI-E slot.
SMBus to PCI-E Slots
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled
Pins 2-3 Disabled (Default)
Manufacturing Mode Select



Manufacturing Mode
Jumper Settings
Jumper Setting Denition
Pins 1-2 Normal (Default)
Pins 2-3 Manufacturing Mode
VGA Enable/Disable

settings.
VGA Enable/Disable
Jumper Settings
Jumper Setting Denition
Pins 1-2 Enabled (Default)
Pins 2-3 Disabled
OCuLink Interface Selection

OCuLink Interface Selection
Jumper Settings
Jumper Setting Denition
Pins 1-2 SATA
Pins 2-3 PCI-E
