Chapter 1: Introduction
Quick Reference Table
Jumper Description Default Setting
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 CMOS Clear Open (Normal)
JI
2
C1/JI
2
C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disable)
JPG1 VGA Enable/Disable Pins 1-2 (Enabled)
JPL1 LAN Enable/Disable Pins 1-2 (Enabled)
JPME2 ME Manufacturing Mode Pins 1-2 (Normal)
JWD1 Watch Dog Pins 1-2 (Reset)
LED Description Status
LED1 Onboard Power LED Solid Green: Power On
LEDM1 BMC Heartbeat LED Blinking Green: BMC Normal
UIDLED1 UID LED
Connector Description
BT1 Onboard Battery
COM1 COM Header
FAN1 ~ FAN3, FANA System/CPU Fan Headers (FAN1: CPU Fan)
IPMI LAN Dedicated IPMI LAN Port
I-SATA0 ~ I-SATA3 Intel SATA 3.0 Ports (I-SATA0 supports SuperDOM)
JD1 Speaker Header
JF1 Front Control Panel Header
JGP1 General Purpose I/O Header
JL1 Chassis Intrusion Header
JMD1 M.2 PCI-E 3.0 x2 / I-SATA Slot (Not available on -2C model)
JPH1
4-pin Power Connector for HDD use (To provide power from the motherboard to
onboard HDD devices)
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPV1
4-pin DC Power Connector (To provide alternative power for special enclosure when the
24-pin ATX power is not in use.)
JPW1 24-pin ATX Power Connector
JRT3 Thermal Diode 1 Header
JRT4 Thermal Diode 2 Header
JSAS1 I-SATA Ports 4-7
JSAS2 I-SATA Ports 8-11 (Not available on -2C/-4C models)
JSD1 SATA DOM Power Connector
JSMB1 SMBus Header
JTGLED1 LAN3/LAN4 Front Activity LED
JTPM1 Trusted Platform Module/Port 80 Connector
LAN1 ~ LAN4 Gigabit Ethernet (RJ45) Ports
