SuperWorkstation 7049GP-TRT User's Manual
Rear Chassis Features
Item Feature Description
1 Power 2x 2200W redundant power supply with PMBus
2 COM Serial Port
3 USB Two USB 3.0 ports and two USB 2.0 ports
4 LAN Two RJ45 10GBase-T ports
5 IPMI RJ45 Dedicated IPMI LAN port
6 FAN Two rear fans
7 Video VGA port
8 PCI-E Four PCI-E 3.0 x16 (double-width) slots
9 PCI-E Two PCI-E 3.0 x16 slots and one PCI-E 2.0 x4 slot
Figure 1-3. Chassis Rear View
Rear Features
The illustration below shows the features included on the rear of the chassis.
1
9
8
7
6
5
432
