11
Chapter 1: Introduction
Front Chassis Features
Item Feature Description
1 Control Panel Front control panel (see preceding page).
2 Bezel Lock Locks the bezel for secure access.
3 Hot-swap Drive Bays Eight 3.5'' drive bays.
Figure 1-2. Chassis Front View
Front Features
The SC-747BTS-R2K20BP is 4U rackmount/tower chassis See the illustration below for the
features included on the front of the chassis.
1
2
3
