138
Super X11DPH-i/X11DPH-T/X11DPH-Tq User's Manual
BIOS Beep (POST) Codes
Beep Code Error Message Description
1 beep Refresh Circuits have been reset (Ready to power up)
1 long continuous System Overheat System overheat
5 short, 1 long Memory error No memory detected in system
5 long, 2 short Display memory read/write error Video adapter missing or with faulty memory
Appendix A
BIOS Codes
A.1 BIOS Error POST (Beep) Codes
Note: For BIOS beep codes to work properly, please connect an optional external
speaker to the speaker/buzzer header located at JD1. Please refer to Chapter 2 for
more information on JD1.
During the POST (Power-On Self-Test) process, which is performed each time the system is
powered on, system errors may be detected.
Non-fatal errors are those which, in most cases, allow the system to continue with the boot-
up process. The error messages normally appear on the screen.
Fatal errors are those which will not allow the system to continue with bootup. If a fatal error
occurs, you should consult with your system manufacturer for possible repairs.
The fatal errors are usually communicated through repeated patterns of audible beeps. Each
pattern of audible beeps listed below corresponds to its respective error.
