Super X11DPH-i/X11DPH-T/X11DPH-Tq User's Manual
Overview of the Processor Socket Assembly
The processor socket assembly contains 1) the Intel Xeon Scalable-SP or
2nd Generation Intel Xeon Scalable-SP processor, 2) the narrow processor clip, 3) the dust
cover, and 4) the CPU socket.
3. Dust Cover
4. CPU Socket
1. Intel Processor
Note: Be sure to cover the CPU socket with the dust cover when the CPU is not in-
stalled.
2. Narrow processor clip (the plastic processor package carrier used for the CPU)
