37
Chapter 2: Installation
DCPMM Memory Population Tables for 2nd Gen Intel Xeon Scalable-SP
Processors
Symmetric Population within 1 CPU Socket
Modes P1-DIMMF1 P1-DIMME1 P1-DIMMD1 P1-DIMMD2 P1-DIMMA2 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 Channel Confi g.
AD DRAM1 DRAM1 DRAM1 DCPMM DCPMM DRAM1 DRAM1 DRAM1 2-1-1
MM DRAM2 DRAM2 DRAM2 DCPMM DCPMM DRAM2 DRAM2 DRAM2 2-1-1
AD + MM DRAM3 DRAM3 DRAM3 DCPMM DCPMM DRAM3 DRAM3 DRAM3 2-1-1
AD DCPMM DRAM1 DRAM1 - - DRAM1 DRAM1 DCPMM 1-1-1
MM DCPMM DRAM1 DRAM1 - - DRAM1 DRAM1 DCPMM 1-1-1
AD + MM DCPMM DRAM3 DRAM3 - - DRAM3 DRAM3 DCPMM 1-1-1
Asymmetric Population within 1 CPU Socket
Modes P1-DIMMF1 P1-DIMME1 P1-DIMMD1 P1-DIMMD2 P1-DIMMA2 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 Channel Confi g.
AD DRAM1 DRAM1 DRAM1 - DCPMM DRAM1 DRAM1 DRAM1 2-1-1
AD* DRAM1 DRAM1 DRAM1 - DCPMM DRAM1 DRAM1 DRAM1 2-1-1
Legend
(for the two tables above)
DDR4 Type Capacity
DRAM1 RDIMM 3DS RDIMM LRDIMM 3DS LRDIMM
Refer to Validation Matrix (DDR4 DIMMs validated with
DCPMM) below.
DRAM2 RDIMM - - -
DRAM3 RDIMM 3DS RDIMM LRDIMM -
Note: DDR4 single rank x8 is not available for DCPMM Memory Mode or App-Direct Mode.
Legend
(for the fi rst two tables above)
Capacity
DCPMM Any Capacity (Uniformly for all channels for a given confi guration)
• * 2nd socket has no DCPMM DIMM
• For MM, general NM/FM ratio is between 1:4 and 1:16. Excessive capacity for FM can be used for AD. (NM = Near
Memory; FM = Far Memory)
• For each individual population, rearrangements between channels are allowed as long as the resulting population is
compliant with the memory rules for 2nd Gen Intel Xeon Scalable-SP (82xx/62xx/52xx/42xx series) processors.
• For each individual population, please use the same DDR4 DIMM in all slots.
• For each individual population, sockets are normally symmetric with exceptions for 1 DCPMM per socket and 1 DCPMM
per node case. Currently, DCPMM modules operate at 2666 MHz.
• No mixing of DCPMM and NVMDIMMs within the same platform is allowed.
• These DCPMM population tables target a balanced DCPMM-to-DRAM-cache ratio in MM and MM + AD modes.
Validation Matrix (DDR4 DIMMs Validated w/DCPMM)
DIMM Type
Ranks Per DIMM
& Data Width
(Stack)
DIMM Capacity (GB)
DRAM Density
4Gb 8Gb
RDIMM
1Rx4 8GB 16GB
2Rx8 8GB 16GB
2Rx4 16GB 32GB
LRDIMM 4Rx4 N/A 64GB
LRDIMM 3DS 8Rx4 (4H) N/A 128GB
Note: Only 2nd Gen Intel Xeon Scalable-SP (82xx/62xx/52xx/42xx series) processors
support DCPMM memory.
