Super X11DPH-i/X11DPH-T/X11DPH-Tq User's Manual

*If SpeedStep (P-States) is set to Enable, the following items will display:

Conﬁ g (Conﬁ guring) TDP (Available when SpeedStep is set to Enable and when

the 2nd Gen Intel Xeon Scalable-SP 8260Y/6240Y/4214Y Processors are Used)

This feature allows the user to conﬁ gure the maximum CPU TDP (Thermal Design Power)

level for the system. The TDP level is subject to chassis and heatsink cooling restrictions.

For proper thermal management, please check the chassis and heatsink speciﬁ cations

for proper CPU TDP sizing. The options are Normal, Level 1 and Level 2.

Intel Speed Select (Available when SpeedStep is set to Enable and when the 2nd

Gen Intel Xeon Scalable-SP 8260Y/6240Y/4214Y Processors are Used)

This feature allows the user to conﬁ gure up to two additional base frequency settings

for the processors used in your system as shown in the display below. The options are

Base, Conﬁ g (Conﬁ guration) 1 and Conﬁ g (Conﬁ guration) 2.

Activate PBF (Available when SpeedStep is set to Enable and when the 2nd Gen

Intel Xeon Scalable-SP 6252N/6230N/5218N Processors are Used)

Select Enable to support Prioritized Base Frequency (PBF), which will increase the base

frequency on high-priority cores and decrease the base frequency on low-priority cores

to improve CPU performance. The options are Disable and Enable.

Conﬁ gure PBF (Available when Activate PBF is set to Enable)

Select Enable to allow the BIOS to conﬁ gure high priority CPU cores as Prioritized Base

Frequency (PBF) so that software programs do not have to conﬁ gure the PBF settings.

This feature is available when it is supported by the CPUs used in the system. The op-

tions are Enable and Disable.
