Page #13 background image
Chapter 1: Overview
1-5
X9DRD-iF/LF Jumpers
Jumper
Description Default Setting
JBT1
Clear CMOS See Chapter 2
JI
2
C1/JI
2
C2
SMB to PCI-E Slots Off (Disabled)
JPB1 BMC Enabled Pins 1-2 (Enabled)
JPG1 VGA Enabled Pins 1-2 (Enabled)
JPL1 GLAN1/GLAN2 Enable Pins 1-2 (Enabled)
JPME1 Management Engine (ME)
Recovery Mode Enable
Pins 1-2 (Normal)
JPME2 (X9DRD-iF) Management Engine (ME)
Manufacture Mode Select
Pins 1-2 (Normal)
JWD1 Watch Dog Timer Enable Pins 1-2 (Reset)
Connectors
Connectors Description
COM1/COM2
(COM1 only: X9DRD-LF)
(COM1/COM2: X9DRD-iF)
Backplane COM Port1/Front Accessible COM2 Header
FAN1~8
(FAN1~6: X9DRD-LF)
(FAN1~8: X9DRD-iF)
CPU/System Fan Headers
I-SATA 0~5 (X9DRD-iF)
I-SATA 0~1 (X9DRD-LF)
Four SATA 2.0 and Two SATA 3.0 Connectors from AHCI
Two SATA 3.0 Connectors from AHCI
JBAT1 Onboard Battery (See Chpt. 3 for Used Battery Disposal)
JD1 Speaker/Power LED Indicator
JF1 Front Panel Control Header
JIPMB1 (X9DRD-iF) 4-pin External BMC I
2
C Header (for an IPMI Card)
JL1 (X9DRD-iF) Chassis Intrusion
JOH1 (X9DRD-iF) Overheat LED Indicator
JPI
2
C1 Power Supply SMBbus I
2
C Header
JPW1 24-Pin ATX Main Power Connector (Warning on Pg. 1-6.)
JPW2/3 12V 8-Pin Power Connectors (See Warning on Pg. 1-6.)
JPW4/5 12V 4-Pin Power Connectors (See Warning on Pg. 1-6.)
JSD1 (X9DRD-iF) SATA DOM (Device on Module) Power Connector
JSTBY1 (X9DRD-iF) +5V Standby Power Header
JTPM1 TPM (Trusted Platform Module)/Port 80
JP2 Manufacture (ME) Mode Pins 1-2 (Normal)
JPME1 ME Recovery Pins 1-2 (Normal)
JVRMI
2
C1/
JVRMI
2
C2
CPU1/CPU2 VRM SMbus Enable Pins 1-2 (Normal)
Note: PCI-E slots support Low-Prole MD2 form factor for devices/add-on
cards that are shorter than 167.64mm or 6.59" (in) in length only.
