Supermicro X9DRD-LF User Manual

Chapter 1: Overview
1-7
Motherboard Features
CPU
• Dual Intel
®
E5-2600(v2) Series Processors (Socket R
LGA 2011); each processor supports four full-width Intel
QuickPath Interconnect (QPI) links (with support of up
to 25.6 GT/s per QPI link and with Data Transfer Rate
of up to 8.0 GT/s per direction).
Note: For Intel E5-2600(v2) processor support,
BIOS version 3.0 or above is required.
Memory
• Integrated memory controller supports up to 512 GB
of Load Reduced (LRDIMM), 256 GB of Registered
(RDIMM) or 64 GB of Unbuffered (UDIMM) ECC/Non-
ECC DDR3 800/1066/1333/1600/1866 MHz 240-pin
4-channel memory modules in eight DIMM slots.
Note 1: 1866 MHz memory speed is dependent
on Intel E5-2600v2 CPUs.
Note 2: For the latest memory updates, please
refer to the Tested Memory List posted on our
website (http://www.supermicro.com/products/
motherboard).
• Virtualization: VT-x, VT-d, and VT-c
Chipset
• Intel® C602 Chipset
Expansion
• Four (4) PCI Express 3.0 x8 slots (CPU1 Slot3/Slot4/
Slot5 and CPU2 Slot 7)
(X9DRD-iF)
• One (1) PCI Express 3.0 x16 slot (CPU2 Slot6)
(X9DRD-iF)
• One (1) PCI Express 3.0 x16 slot (from P1PE2) (See
note on page 1-5)
(X9DRD-LF)
Slots
Graphics
• Nutovon BMC Video Controller (Matrox G200eW)
Network
• One Intel I350 Gigabit (10/100/1000 Mb/s) Ethernet Dual
Port Controller for LAN 1/LAN 2 ports.
• Nuvoton WPCM450 Base-board Controller (BMC) sup-
ports IPMI_LAN 2.0

Supermicro X9DRD-LF Specifications

General

IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Maximum UDIMM memory	64 GB
Number of DIMM slots	8
Supported RDIMM clock speeds	800, 1066, 1333, 1600 MHz
Supported DIMM module capacities	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
PCI Express slots version	3.0
Memory voltage	1.35, 1.5 V
Maximum RDIMM memory	256 GB
Supported memory types	DDR3-SDRAM
BIOS type	AMI
ACPI version	4.0
BIOS memory size	128 Mbit
RAID levels	0, 1
Supported storage drive interfaces	SATA III
On-board graphics card model	Matrox G200eW
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	8 GT/s
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Processor manufacturer	Intel
Ethernet interface type	Gigabit Ethernet
Component for	Server
Motherboard chipset	Intel® C602
Sustainability certificates	RoHS

Weight and Dimensions

Depth	330 mm
Width	262 mm
