Supermicro X9DRD-LF User Manual

1-10
X9DRD-iF/LF Motherboard User’s Manual
System Block Diagram
Note: This is a general block diagram and may not exactly represent the
features on your motherboard. See the Motherboard Features pages for
the actual specications of each motherboard.
X9DRD-iF Block Diagram
PROCESSOR 1 (left)
#1
DDR3 DIMM
DDR3 DIMM DDR3 DIMM
#1
DDR3 DIMM
A
SSB
PCH C602
DMI
PET [1~4]
USB
W25Q128
LPC
USB
REAR
HDR 2X5
0,1
TYPE-A
TPM HDR
REAR
2,3
DDR3 DIMM
B
DDR3 DIMM
D
C
F
E
#1
#1
#1
#1
P0 P1
DMI
PE2
(C,D)
PE2
(A,B)
PE1
(A,B)
DMI
HDR 2X5
VGA
VGA CONN
DDR III
PHY1
IPMI LAN
RTL8201F
SPI
SATA #1
SCU
PCI
SIO
W83527
x4 (LANE1~4)
I350
GLAN
RJ45 RJ45
SATA #2 SATA #3 SATA #4
PEG0 [0..3]
JPCIE3
PCIE 3.0 x8
JPCIE4
PCIE 3.0 x16
JPCIE5
PCIE 3.0 x8
PE3
(A,B)
PE3
(C,D)
JPCIE1 PCIE 3.0 x8
JPCIE2
PCIE 3.0 x8
PE1
(A,B)
PE2
(A,B)
PE2
(C,D)
PE3
(A,B)
QPI
QPI
PE3
(C,D)
SATA #6 SATA #7 SATA #8
SATA #5 SATA #10 SATA #9
AHCI
6
8,9
4,5
BMC
PE1
PE2
PE3
PROCESSOR 2 (right)
DDR3 DIMM
G
#1
DDR3 DIMM
H
#1

Supermicro X9DRD-LF Specifications

General

IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
Maximum UDIMM memory	64 GB
Number of DIMM slots	8
Supported RDIMM clock speeds	800, 1066, 1333, 1600 MHz
Supported DIMM module capacities	16GB, 1GB, 2GB, 32GB, 4GB, 8GB
PCI Express slots version	3.0
Memory voltage	1.35, 1.5 V
Maximum RDIMM memory	256 GB
Supported memory types	DDR3-SDRAM
BIOS type	AMI
ACPI version	4.0
BIOS memory size	128 Mbit
RAID levels	0, 1
Supported storage drive interfaces	SATA III
On-board graphics card model	Matrox G200eW
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	8 - 90 %
Supported QPI	8 GT/s
Processor socket	LGA 2011 (Socket R)
Intel Xeon series	E5-2600
Processor manufacturer	Intel
Ethernet interface type	Gigabit Ethernet
Component for	Server
Motherboard chipset	Intel® C602
Sustainability certificates	RoHS

Weight and Dimensions

Depth	330 mm
Width	262 mm
