Chapter 1: Introduction
1-5
X8DA3/X8DAi Quick Reference
Jumper Description Default Setting
JBT1 CMOS Clear (See Chapter 2)
JI
2
C1/JI
2
C2 SMB to PCI-Exp. Slots Pins 2-3 (Disabled)
JI
2
C3/JI
2
C4 SMB to PCI-X Slots Pins 2-3 (Disabled)
JPI1 CNF1/CNF2 (1394a_1/2) Enable Pins 1-2 (Enabled)
JPL1/JPL2 LAN1/2 Enable Pins 1-2 (Enabled)
JPS1 SAS Enable (X8DA3) Pins 1-2 (Enabled)
JPS2 SAS RAID Mode Select (X8DA3) Closed (SR RAID Enabled)
JWD1 Watch Dog Pins 1-2 (Reset)
Connector Description
Audio/CD1/JC2 Audio Input_Output_Mic/CD-ROM/HD Audio Headers
CNF1/CNF2 IEEE 1394a Connectors 1/2
COM1/COM2 COM1/COM2 Serial Ports
FAN 1-8 System/CPU Fan Headers (Fans 7~8: CPU Fans)
Floppy Floppy Disk Drive Connector
J5 SMB I
2
C Header
JD1 Speaker/Power LED Header
JF1 Front Panel Connector
JL1 Chassis Intrusion Header
JOH1 Overheat LED Header
JPI
2
C Power Supply SMBus I
2
C Header
JPW1/JPW2 +12V 8-pin Secondary PWR Connector (See P. 1-4)
JPW3 24-pin ATX Main Power Connector (See P. 1-4)
JWOL1 Wake-On-LAN Header
LAN1/2 Gigabit Ethernet (RJ45) Ports
I-SATA0 ~ I-SATA5 (Intel South Bridge) SATA Ports
SAS 0~3, 4~7 SAS Connectors (X8DA3 only)
SIMLC (Low Profi le) SIMLC IPMI 2.0 Socket
T-SGPIO-1/T-SGPIO-2 Serial General Purpose Input/Output Headers
(B/P) USB0/1/2/3 (Back Panel) Universal Serial Bus (USB) Ports
F/P USB 4/5, 6/7, 8 Front Panel Accessible USB Headers
LED Description
LE1 Onboard Standby PWR warning LED Indicator
LES1 SAS Activity LED (Green: SAS Active) (X8DA3 only)
LES 2 SAS Link LEDs (X8DA3 only)
